Stealth 1565
The Stealth 1565 is a high-speed vertical machining center that features four Y-axis box guideways, a Meehanite cast iron base, and powerful drive motors on the X, Y and Z axes. Ideal for job shop applications, the Stealth is as efficient as it is accurate.
Se interessou? Peça seu orçamento
| Table Size | 65" x 25.6" (1,650 mm x 650 mm) |
| X-Axis Travel | 59.1" (1,500 mm) |
| Y-Axis Travel | 25.6" (650 mm) |
| Z-Axis Travel | 23.6" (600 mm) |
| Maximum Table Load | 3,306 lb (1,500 kg) |
| Distance from Spindle Nose to Table Top | 4.9" to 28.5" (125 mm to 725 mm) |
| Spindle Drive Motor (30 min. / cont.) | Gearbox (CAT40): 20 HP (15 kW) / 15 HP (11 kW) |
| Spindle Drive Motor (30 min. / cont.) | Gearbox (CAT50): 25 HP (18.5 kW) / 20 HP (15 kW) |
| Spindle Drive Motor (30 min. / cont.) | Direct Drive (CAT40): 25 HP (18.5 kW) / 20 HP (15 kW) |
| Spindle Output Torque | Gearbox (CAT40): 282 ft-lb (380 Nm) |
| Spindle Output Torque | Gearbox (CAT50): 339 ft-lb (460 Nm) |
| Spindle Output Torque | Direct Drive (CAT40): 92 ft-lb (125 Nm) |
| Spindle Speed | Gearbox (CAT40): 8,000 RPM |
| Spindle Speed | Gearbox (CAT50): 6,000 RPM |
| Spindle Speed | Direct Drive (CAT40): 12,000 RPM |
| Rapid Feedrate (X axis) | 1,181 ipm (30 m/min) |
| Rapid Feedrate (Y axis) | 1,181 ipm (30 m/min) |
| Rapid Feedrate (Z axis) | 945 ipm (24 m/min) |
| Maximum Cutting Feedrate | 945 ipm (24 m/min) |
| Tool Storage Capacity | 24 Standard |
| Machine Weight | 17,857 lb (8,100 kg) |
| Standard Floor Space | 205" x 118" x 116" (5,218 mm x 2,990 mm x 2,940 mm) |
